Technical Drawing for Product Design: Mastering ISO GPS and ASME GD&T

di Stefano Tornincasa (Autore)

Springer Nature Switzerland AG, 2020

This book is intended for students, academics, designers, process engineers and CMM operators, and presents the ISO GPS and the ASME GD&T rules and concepts. The Geometric Product Specification (GPS) and Geometrical Dimensioning and Tolerancing (GD&T) languages are in fact the most powerful tools available to link the perfect geometrical world of models and drawings to the imperfect world of manufactured parts and assemblies. The topics include a complete description of all the ISO GPS terminology, datum systems, MMR and LMR requirements, inspection, and gauging principles. Moreover, the differences between ISO GPS and the American ASME Y14.5 standards are shown as a guide and reference to help in the interpretation of drawings of the most common dimensioning and tolerancing specifications.The book may be used for engineering courses and for professional grade programmes, and it has been designed to cover the fundamental geometric tolerancing applications as well as the more advanced ones. Academics and professionals alike will find it to be an excellent teaching and research tool, as well as an easy-to-use guide.

• Autore: Stefano Tornincasa
• Editore: Springer Nature Switzerland AG
• Collana: Springer Tracts in Mechanical Engineering
• Anno: 2020
• Rilegatura: Hardback
• Pagine: 306 p.
• Dimensioni: 235 x 155 mm
• EAN: 9783030608538

Testo in English
